SP-SG307 aluminium BNC video surge protector with ground lead

Model: SP-SG307

BNC Video Surge Protector

Inline BNC surge protector for analog and HD-over-coax cameras (AHD, TVI, CVI, CVBS).

BNC
Imax 10 kA
Response ≤ 1 ns

Minimum order: On request
Samples: Available
OEM: Logo & packaging

Get a Quote for SP-SG307

Specifications

Interface	BNC in / BNC out
Signals	Analog CCTV video (CVBS, AHD, TVI, CVI)
Operating voltage	5 V
Nominal discharge current (In)	5 kA
Max discharge current (Imax)	10 kA
Response time	≤ 1 ns
Operating temperature	-20 to +70 °C
Size	77 × 25 × 25 mm
Weight	0.12 kg
Housing	Aluminium alloy, with ground lead

Manufacturer specification. Contact us to confirm compatibility with your equipment before ordering.

Typical use

Fit inline on the coax at the camera and at the DVR input for cameras on exposed outdoor runs. Connect the ground lead to earth.

Notes before ordering

For video signals only. It does not protect a power-over-coax (PoC) supply; tell us if your cameras use PoC.
