Model: SP-SG302
Gigabit Ethernet Surge Protector, RJ45
Inline RJ45 surge protector for IP cameras and PoE switches on outdoor or long cable runs. Gigabit data, shielded aluminium housing, ground lead included.
- 1000 Mbps
- Imax 10 kA
- Response ≤ 1 ns
- Minimum order
- 10 pcs
- Samples
- Available
Specifications
| Data rate | 10/100/1000 Mbps |
|---|---|
| Connector | RJ45 in / RJ45 out |
| PoE lines | For 48 V PoE lines (manufacturer listing) |
| Max discharge current (Imax) | 10 kA |
| Nominal discharge current (In) | 5 kA |
| Voltage protection level | ≤ 15 V |
| Response time | ≤ 1 ns |
| Insertion loss | ≤ 0.5 dB |
| Housing | Shielded aluminium alloy, with ground wire |
Manufacturer specification. Contact us to confirm compatibility with your equipment before ordering.
Typical use
Install one protector at each end of an exposed cable run: next to the outdoor camera and next to the switch or NVR port. Connect the ground lead to a proper earth.
Notes before ordering
- Protection depends on a good earth connection. An unearthed protector gives little protection.
- Listed by the manufacturer for 48 V PoE lines. Tell us the switch and camera models and we will confirm before you order.
