Model: SP-SG304
Outdoor PoE Surge Protector, Gigabit, IP66
Weatherproof inline surge protector for PoE cameras. Protects all eight wires of a gigabit PoE link at the camera end.
- IP66
- PoE 12–57 V
- Gigabit
- Imax 5 kA
- Minimum order
- On request
- Samples
- Available
Specifications
| Data rate | 10/100/1000 Mbps |
|---|---|
| PoE / operating voltage | DC 12–57 V |
| Protected pairs | 1/2, 3/6, 4/5, 7/8 |
| Nominal discharge current (In) | 2.5 kA |
| Max discharge current (Imax) | 5 kA |
| Voltage protection level | ≤ 60 V |
| Response time | ≤ 0.1 ns |
| Insertion loss | ≤ 0.5 dB |
| Connector | RJ45 in / RJ45 out |
| IP rating | IP66, ABS housing with sealed glands |
Manufacturer specification. Contact us to confirm compatibility with your equipment before ordering.
Typical use
Install inline next to an outdoor PoE camera, with a second protector at the switch end for long exposed runs. Connect the ground lead to a proper earth.
Notes before ordering
- Protection depends on a good earth connection.
- Protects all four pairs, so it suits both mode A and mode B PoE.
