Model: SP-SG305
2-in-1 Network & 220 V Power Surge Protector
Protects both the Ethernet line and the 220 V AC supply of an outdoor camera in one unit.
- RJ45 + 220 V AC
- Imax 10 kA
- Gigabit
- Minimum order
- On request
- Samples
- Available
Specifications
| Protected lines | Ethernet (RJ45) + 220 V AC power |
|---|---|
| Data rate | 10/100/1000 Mbps |
| Max discharge current (Imax) | 10 kA |
| Nominal discharge current (In) | 5 kA |
| Response time | ≤ 1 ns |
| Housing | Shielded aluminium alloy, with ground wire and mounting flanges |
Manufacturer specification. Contact us to confirm compatibility with your equipment before ordering.
Typical use
Mount next to an outdoor camera that has both a network cable and a local 220 V AC supply. Wire the AC supply through the power terminals, route the network cable through the RJ45 ports and connect the ground lead to earth.
Notes before ordering
- For 220 V AC mains only. It is not suitable for 110–120 V supplies.
- AC power wiring must be done by a qualified electrician according to local regulations.
