Model: SP-VB331
Active HD Video Balun, 400 m
Active balun with signal LED and 2 kV transient protection for longer twisted-pair runs.
- Active
- 400 m
- 2 kV protection
- Minimum order
- 1 pair
- Samples
- Available
Specifications
| Signals | CVI, TVI, AHD, CVBS (NTSC / PAL) |
|---|---|
| Bandwidth | 0–80 MHz |
| Distance | Up to 400 m (manufacturer rating) |
| Connector | Pure copper BNC male, 75 Ω; press terminal |
| Power | < 0.15 W |
| Transient protection | 2 kV |
| Operating temperature | -10 to +70 °C |
| Size | 55 × 28.6 × 20 mm |
Manufacturer specification. Contact us to confirm compatibility with your equipment before ordering.
