Model: SP-VB310
Audio, Video & Power Balun with RJ45
RJ45 balun with BNC, RCA and DC leads for cameras with audio, powered over the same cable.
- BNC + RCA + DC
- Up to 8MP
- 100–400 m
- Minimum order
- 1 pc
- Samples
- Available
Specifications
| Signals | AHD, TVI, CVI, CVBS + audio |
|---|---|
| Resolution | 720P to 8MP |
| Connections | BNC, RCA, DC + RJ45 |
| Distance | 100–400 m (manufacturer rating) |
| Power output | 12 V 1 A |
| Housing | ABS, black |
Manufacturer specification. Contact us to confirm compatibility with your equipment before ordering.
