SP-PS301 wall-plug PoE injector with LAN and PoE RJ45 ports

Model: SP-PS301

PoE Injector, 48 V 0.5 A, Wall Plug

Adds IEEE 802.3af PoE to a single camera or access point from a non-PoE switch or router. Plugs straight into the wall.

48 V 0.5 A
802.3af
Wall plug

Minimum order: 1 pc
Samples: Available
OEM: Logo & packaging

Specifications

PoE standard	IEEE 802.3af
AC input	100–240 V AC, 50/60 Hz
PoE output	48 V DC, 0.5 A
Data rate	10/100 Mbps
Ports	1 × LAN in, 1 × PoE out (RJ45)
Plug type	US, EU, UK or AU
Housing	ABS + PC, flame retardant

Manufacturer specification. Contact us to confirm compatibility with your equipment before ordering.

Typical use

Plug the injector into a wall outlet near the switch. Connect the switch port to LAN and run the cable from PoE out to the camera. Use one injector per camera.

Notes before ordering

State the plug type for your market when requesting a quote.
12 V and 24 V passive versions also exist. They are not IEEE 802.3af and can damage standard PoE devices; ask only if your equipment specifically requires passive PoE.
